KIV90XE
10 in stock
Product family: Hood
Subfamily: Decorative island hood
Aesthetics: Universale
Serie: Universale
Colour: Stainless steel
Hood width: 90 cm
Energy efficicency class ( EEC): B
Type
Product family: Hood
Hood Type: Decorative island hood
Hood width: 90 cm
Extraction: Extraction
Electronic control: Yes
EAN code: 8017709204075
Aesthetics
Colour: Stainless steel
Finishing: Satin
Aesthetics: Universale
Design: Curved
Material: Stainless steel
Type of steel: Brushed
Glass Type: Clear
Controls
Control setting: Electronic buttons
Led color: White
Programs / Functions
No. of speeds: 3
Intensive speed: Yes
Time-setting options: Automatic switch-off
Technical Features
No. of lights: 4
Light type: LED
Light Power: 1 W
Light color temperature scale (°K): 4000 °K
Free outlet maximum capacity: 820 m³/h
Motor power: 275 W
No. of filters: 2
Anti-grease filters: Aluminium
Filter replacement indicator: Yes
Vent outlet: 150 mm
Non return valve: Yes
Performance / Energy Label
Energy efficicency class ( EEC): B
Fluid Dynamic Efficiency class (FDEC): A
Grease Filtering Efficiency Class (GFEC): C
Lighting Efficiency Class (LEC): A
Annual Efficiency Consumption (AEChood): 64,4 kWh/a
Fluid Dynamic Efficiency (FDE): 28,6
Lighting Efficiency (LE): 91,8 lux/W
Grease Filtering Efficiency (GFE): 84,5 %
Air flow at minumum speed (Qmin): 310 m³/h
Air flow at maximum speed (Qmax): 535 m³/h
Air flow at boost speed (Qboost): 760 m³/h
Airbourne acouistical A-weighted sound Power Emission at minimum speed (SPEmin): 50 dB(A)
Airborne acoustical A-weighted sound Power Emission at maximum speed (SPEmax): 62 dB(A)
Airbourne acoustical A-weighted sound power emission at boost speed (SPEboost): 71 dB(A)
Power consumption in stand-by mode (Ps): 0,49 W
Time increase factor (F): 1
Measured air flow rate at best efficiency point (Qbep): 417 m³/h
Measured air pressure at best efficiency point (Pbep): 426 Pa
Measured electric power input at best efficiency point (Wbep): 173 W
Nominal Power consumption of the light system (WL): 4 W
Average illumination of the light on the cooking surface (Emiddle): 404 lux
Sound power level at highest setting (Lwa): 62 dB(A)
Electrical Connection
Electrical connection rating: 280 W
Voltage: 220-240 V
Frequency (Hz): 50-60 Hz
Speed 1
Extraction rate IEC 61591: 310 m³/h
Noise level IEC 60704-2-13: 50 dB(A)
Power: 196 W
Speed 2
Extraction rate IEC 61591: 387 m³/h
Noise level IEC 60704-2-13: 58 dB(A)
Power: 230 W
Speed 3
Extraction rate IEC 61591: 535 m³/h
Noise level IEC 60704-2-13: 62 dB(A)
Power: 279 W
Intensive speed
Extraction rate (IEC 61591): 750 m³/h
Noise level IEC 60704-2-13: 71 dB(A)
Power: 305 W
Logistic Information
Dimensions of the product (mm): 870x898x560
Width: 898 mm
Depth (mm): 560 mm
Product Height (mm): 870 mm
| Aesthetic |
Universal |
|---|---|
| Colour |
Stainless Steel |
| Energy Efficiency Class |
B |
| Hood width |
90 cm |
| Product Family |
Hood |
